High-capacity 1GE and 10GE chassis LAN switches that provide secure, high-availability core switching for large enterprise, campus and metro Ethernet networks.

Alcatel-Lucent OmniSwitch 9000E switches offer secure, high capacity aggregation and core switching. They were designed for deployments requiring high capacity, scalability and virtualization. Smart continuous switching for non-stop operation in redundant systems, together with in-service software upgrades mean your network is always available.

Highlights
  • Meet the needs of your large enterprise, campus, data center or metro environment
  • Keep your network running with redundant, always-on availability
  • Provide secure voice, data and video services



Features

  • Wire-rate processing for simultaneous Layer 2/IPv4/IPv6 traffic (unicast and multicast)
  • High density with GigE (up to 384 ports) and 10GigE (up to 192 ports)
  • Up to 64,000 media access control (MAC) addresses per chassis, up to 4,094 VLAN IDs
  • Layer 2 deployment using stacked virtual LANs (VLANs), including operations, administration and maintenance (OA&M) toolbox and multicast support
  • Layer 3 deployment using multiple virtual routing and forwarding (VRF)
  • Enhanced VoIP and video performance with policy-based QoS, future-ready support for multimedia applications with wire-rate multicast, and IEEE 802.3at PoE+ support for IP phones, WLAN
  • Access points and video cameras


Benefits
Related Documents
See all assets for this product
Models

Available Models

OmniSwitch 9800E: The highest port density and performance available for large enterprise networks.

OmniSwitch 9700E: All the value of the 9800E in a smaller form factor.
